Description
Product details
Model ATS-303D Process Moisture Analyzer Designed to Handle Rigorous Demands of Moisture Measurement in Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications. The advantages of a linear high capacitance response are: better sensitivity, better repeatability and faster response times. Also, the measurement system is less prone to noise and drift, and signal conditioning is kept to a minimum. The dew point meter is operated through a menu driven user interface consisting of a custom LCD display with backlight, and four push buttons. This dew point system has proven to produce consistently accurate monitoring results for dew point in natural gas and other difficult hydrocarbon processing applications, where conventional analyzers have failed. Features: High Confidence in Measurement Automatic Field-Calibration/Validation Long Sensor Life Low Maintenance and Low Installation Cost Inbuilt thin film capacitive sensor 128 X 64 Graphics LCD Display embedded software for moisture calculation Optional Sampling systems Data Logger with RS 232- USB Computer Interface. Specification: Principle Thin Film Capacitive, Capacitive Aluminum Oxide Range Degree C, PPM & % RH Resolution 0.1 Unit or 1 Unit (Application based) Sampling Method Direct Plug In Display 128 X 64 Graphics LCD Power Source Built in Lithium Rechargeable battery Or 230V AC Accuracy +/2% Response Time <5 Second Data Storage 5000 or 10000 Computer Interface RS 232, USB Analog Output 4-20mA Sensor Life 2-3 Years Operating Time 6 – 8 hours Environmental Temperature 15degree Celsius Humidity < 85%RH Atmosphere Pressure 86- 106Kpa Housing High Impact Plastic Dimension in mm 200 (W) X 120 (H) X 185(D) Weight 1.5 KG Warranty One Year
