Chlorine Gas Analyzer Model ATS- 208A Chlorine Gas Analyzer continuously monitors the concentration of Chlorine in PPM and other gases ranging from 100%V/V down to PPM level. Feature includes a duel wavelength sensor, Remote Sampling, Graphics LCD Display, adjustable level relay output for alarm and 4-20mA output for control purpose and minimal maintenance. Special gas sample Conditioning systems are used to clean and dry the gas sample for accurate and High performance operation. An Internal Pump draw gas sample into the sensor through a dust particle filter from an intake which can be located at distance up to 40 meter form the monitor. Specifications: Principle: Electrochemical, TCD (Thermal Conductivity) , NDIR (Non Dispersive Infrared ), Zirconium and Paramagnetic •Range: %V/V, % LEL, PPM, Mg/M3 •Resolution: 0.1 Unit or 1 Unit (Application based) •Sampling Method: Auto Suction •Display: 320 X 264 Graphic LCD •Alarm; Relay Contact NO NC •Analog Out Put: 4-20mA •Digital Out Put : RS 232, RS 485 and Modbus Communication Protocol •Power Source:230VAC •Accuracy: /2% •Response Time: Sensor Life: 2-3 Years •Temperature:-15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86- 106Kpa •Dimension in mm: 430 (W) X 150(H) X 250(D) •Weight: 2.5 KG
